Prefabricated Hydrogen Peroxide Resistant Cleanroom Panel
Independently developed by Shanghai Pulong Industrial Co., Ltd., the prefabricated hydrogen peroxide resistant cleanroom panel is a high-performance enclosure material designed for scenarios with strict cleanliness standards and frequent disinfection, such as biopharmaceutical workshops and CDC laboratories.
Breaking through corrosion resistance technology against strong oxidizing agents, it solves the long-standing industry pain point that traditional clean panels suffer from aging, rusting and peeling after repeated VHP vaporized hydrogen peroxide sterilization. This product fills the domestic technical gap of hydrogen peroxide-resistant clean enclosure materials, and becomes the preferred material for pharmaceutical & medical cleanroom projects.
Core Structure & Certification
Double-sided 5mm A-class non-combustible stone crystal boards with dense corrosion-resistant surface;
High-strength integrated aluminum keel for fast modular assembly;
100kg/m³ fire-resistant hydrophobic rock wool core for fireproofing and sound insulation.
The panel holds national invention patents, and its technical specifications are incorporated into the latest Construction & Acceptance Standard for Pharmaceutical Industrial Cleanrooms, fully compliant with GMP audit requirements.
Key Performance Features
Excellent VHP Corrosion Resistance
Special modified coating & lamination surface withstands 3% hydrogen peroxide solution. After 600 cycles of VHP disinfection tests, the panel remains 100% intact, while conventional steel panels show 15% surface corrosion after only 30 cycles.Fast Prefabricated Installation
Groove snap joint design with hidden metal hanging beams, joint gap less than 4mm. Construction period reduced by 84% vs traditional hand-made panels, complying with green prefabricated building policies.Fire & Safety Compliance
Fire resistance integrity ≥60 mins (GB/T9978.1-2008), standard B1 flame retardant grade, upgradable to A2 non-combustible; permanent anti-static performance.Long-lasting Antibacterial Property
Overall antibacterial rate over 99%. Non-porous smooth surface repels dust and microbes, easy to wipe and sanitize.
Application & Industry Value
30% lower cost compared with imported equivalent panels;
Service life 3 times longer than traditional clean panels;
40% reduction in long-term maintenance & replacement cost;
Realizes domestic substitution of high-end imported cleanroom materials.
